Description
- Compatible with TTL/RS485 standard, converting the TTL signal into differential RS485 signal, support half-duplex communication
- Compatible with 3.3V ~ 5V TTL signal level, provides anti-reverse and over-voltage protection for power supply interface
- Onboard unibody power supply isolation, provides stable isolated voltage and needs no extra power supply for the isolated terminal
- Onboard unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, low power consumption
- Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, lightningproof & anti-electrostatic
- Onboard resettable fuse and protection diodes, ensures the current/voltage stable outputs, provide over-current/over-voltage protection, improve shock proof performance
- Onboard RS485 output terminal 120R resistor, enabled/disabled via switch
- Industrial rail-mount ABS case design, small in size, easy to install, and cost-effective
Specifications
| PRODUCT TYPE | Galvanic isolated TTL To RS485 converter | |
|---|---|---|
| POWER SUPPLY INTERFACE | Power supply | 3.3V ~ 5V |
| Protection | over-voltage, reverse-proof | |
| DEVICE PORT | TTL/RS485 standard compatible | |
| TTL | Connector | screw terminal |
| Transmission distance | about 10m | |
| Transmission mode | point-to-point | |
| RS485 | Connector | screw terminal |
| Protection | 600W lightningproof and surge-suppress, 15KV ESD protection | |
| Terminal resistor | 120R, enabled/disabled via switch | |
| Transmission Distance | About 1.2km | |
| Transmission Mode | point-to-multipoint (up to 32 nodes, it is recommended to use repeaters for 16 nodes or more) | |
| APPEARANCE | Case | Rail-mount ABS case, suitable for 35mm DIN rail |
| Dimensions | 91.6 × 58.7 × 23.3mm | |
